Access control for Knative Broker with class MTChannelBasedBroker using OpenShift Service Mesh

By default, every workload is allowed to send events to a Knative Broker, with OpenShift Service Mesh, we can apply policies to control who can post events to Knative brokers.

Prerequisites

You have followed the setup Service Mesh with OpenShift Serverless procedure.

Setup procedure

Create a Broker with class MTChannelBasedBroker in a namespace that is member of the ServiceMeshMemberRoll:

apiVersion: eventing.knative.dev/v1
kind: Broker
metadata:
  name: channel-based-broker-br
  namespace: authz-tests (1)
  annotations:
    eventing.knative.dev/broker.class: MTChannelBasedBroker
spec:
  config:
    apiVersion: v1
    kind: ConfigMap
    name: config-br-default-channel
    namespace: knative-eventing

1	A namespace that is member of the `ServiceMeshMemberRoll`.

Apply the Broker resource:
```
$ oc apply -f <filename>
```

Create a ContainerSource in a namespace that is member of the ServiceMeshMemberRoll:

apiVersion: sources.knative.dev/v1
kind: ContainerSource
metadata:
  name: heartbeat-source-mt-channel-based-broker
  namespace: authz-tests (1)
spec:
  template:
    metadata:
      annotations:
        sidecar.istio.io/inject: 'true' (2)
    spec:
      containers:
        - image: quay.io/openshift-knative/heartbeats
          name: heartbeats
          args:
            - --period=1
          env:
            - name: POD_NAME
              value: "mypod"
            - name: POD_NAMESPACE
              value: "authz-tests"
  sink:
    ref:
      apiVersion: eventing.knative.dev/v1
      kind: Broker
      name: channel-based-broker-br

1	A namespace that is member of the `ServiceMeshMemberRoll`.
2	Injects Service Mesh sidecars into the `ContainerSource` pods.

Apply the ContainerSource resource:
```
$ oc apply -f <filename>
```

Create a consumer service, consisting of Trigger, Service, and Pod, in a namespace that is member of the ServiceMeshMemberRoll:

apiVersion: eventing.knative.dev/v1
kind: Trigger
metadata:
  name: channel-based-broker-tr
  namespace: authz-tests (1)
spec:
  broker: channel-based-broker-br
  subscriber:
    ref:
      apiVersion: v1
      kind: Service
      name: event-display
---
apiVersion: v1
kind: Service
metadata:
  name: event-display
  namespace: authz-tests (1)
spec:
  selector:
    app: event-display
  ports:
    - protocol: TCP
      port: 80
      targetPort: 8080
---
apiVersion: v1
kind: Pod
metadata:
  name: event-display
  namespace: authz-tests (1)
  annotations:
    sidecar.istio.io/inject: 'true' (2)
  labels:
    app: event-display
spec:
  containers:
    - name: event-display
      image: quay.io/openshift-knative/knative-eventing-sources-event-display
      ports:
        - containerPort: 8080

1	A namespace that is member of the `ServiceMeshMemberRoll`.
2	Injects Service Mesh sidecars into the pod.

Apply the consumer service resources:
```
$ oc apply -f <filename>
```

Securing access to the Knative Broker

By default, every workload is allowed to send events to a Knative Broker, with OpenShift Service Mesh, we can apply a policy to deny posting events by default.

Apply a deny by default authorization policy

Create a deny by default AuthorizationPolicy in the knative-eventing namespace:
```
apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
  name: deny-all-by-default
  namespace: knative-eventing
spec: { } (1)
```
1 Disallow any operations to every workload that is part of the service mesh in the knative-eventing namespace.
Apply the AuthorizationPolicy resource:
```
$ oc apply -f <filename>
```

Verify access is denied

we have denied access to every workload to the knative-eventing namespace, which disallows the ContainerSource heartbeat-source-mt-channel-based-broker to send events to the Knative Broker channel-based-broker-br, therefore, we should see the following lines in the heartbeats pods:

$ oc logs $(oc get pod -n authz-tests -o name | grep heartbeat-source-mt-channel-based-broker) -c heartbeats -n authz-tests

Example output

2023/06/13 10:17:04 sending cloudevent to http://broker-ingress.knative-eventing.svc.cluster.local/authz-tests/channel-based-broker-br
2023/06/13 10:17:04 failed to send cloudevent: 403:
2023/06/13 10:17:05 sending cloudevent to http://broker-ingress.knative-eventing.svc.cluster.local/authz-tests/channel-based-broker-br
2023/06/13 10:17:05 failed to send cloudevent: 403:

Authorize source to post events to Knative Broker

In the previous section, we denied access to Knative Eventing workloads, we can now grant permissions to post events to a Knative Broker with class MTChannelBasedBroker:

Create a AuthorizationPolicy in the knative-eventing namespace to allow pods in the authz-tests namespace to send events to Knative Brokers in the same authz-tests namespace:

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
  name: allow-authz-tests-mt-channel-based-broker
  namespace: knative-eventing
spec:
  action: ALLOW
  selector:
    matchLabels:
      app.kubernetes.io/component: "broker-ingress" (2)
  rules:
    - from: (1)
        - source:
            namespaces: [ "authz-tests" ]
      to: (2)
        - operation:
            methods: [ "POST" ]
            paths: [ "/authz-tests/*" ] (3)

1	Allow workloads in the `authz-tests` namespace
2	To post events to Knative brokers in the `authz-tests` namespace.
3	Knative Broker with class `MTChannelBasedBroker` accepts events on HTTP path following the pattern: `/<broker-namespace>/<broker-name>`.

Apply the AuthorizationPolicy resource:
```
$ oc apply -f <filename>
```

Create a AuthorizationPolicy in the knative-eventing namespace to allow mt-broker-ingress in the knative-eventing namespace to post events to the InMemoryChannel dispatcher:

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
  name: allow-mt-channel-based-broker-ingress-to-imc-dispatcher
  namespace: knative-eventing
spec:
  action: ALLOW
  selector:
    matchLabels:
      app.kubernetes.io/component: "imc-dispatcher" (2)
  rules:
    - from: (1)
        - source:
            namespaces: [ "knative-eventing" ]
            principals: [ "cluster.local/ns/knative-eventing/sa/mt-broker-ingress" ]
      to: (2)
        - operation:
            methods: [ "POST" ]

1	Allow `mt-broker-ingress` in the `knative-eventing` namespace.
2	To post events to the `InMemoryChannel` dispatcher.

Apply the AuthorizationPolicy resource:
```
$ oc apply -f <filename>
```

Create a AuthorizationPolicy in the knative-eventing namespace to allow imc-dispatcher in the knative-eventing namespace to post events to the mt-broker-filter:

apiVersion: security.istio.io/v1beta1
kind: AuthorizationPolicy
metadata:
  name: allow-imc-dispatcher-to-mt-channel-based-broker-filter
  namespace: knative-eventing
spec:
  action: ALLOW
  selector:
    matchLabels:
      app.kubernetes.io/component: "broker-filter" (2)
  rules:
    - from: (1)
        - source:
            namespaces: [ "knative-eventing" ]
            principals: [ "cluster.local/ns/knative-eventing/sa/imc-dispatcher" ]
      to: (2)
        - operation:
            methods: [ "POST" ]

1	Allow `imc-dispatcher` in the `knative-eventing` namespace.
2	To post events to the `mt-broker-filter`.

Apply the AuthorizationPolicy resource:
```
$ oc apply -f <filename>
```

Verification

You can verify that the events were sent to the Knative event sink by looking at the message dumper function logs.

Enter the command:

$ oc logs $(oc get pod -n authz-tests -o name | grep event-display) -c event-display -n authz-tests

Example output

☁️  cloudevents.Event
Validation: valid
Context Attributes,
  specversion: 1.0
  type: dev.knative.eventing.samples.heartbeat
  source: https://knative.dev/eventing-contrib/cmd/heartbeats/#event-test/mypod
  id: 2b72d7bf-c38f-4a98-a433-608fbcdd2596
  time: 2019-10-18T15:23:20.809775386Z
  contenttype: application/json
Extensions,
  beats: true
  heart: yes
  the: 42
Data,
  {
    "id": 1,
    "label": ""
  }
